A.5 WISE-4012E Wireless Modbus Mapping Table
Address 0X Channel Description Attribute
00001 0
DI Value
Read
00002 1 Read
00017 0
DO Value
R/W
00018 1 R/W
00033 0 Counter Status
(0: stop
1: start)
R/W
00034 1 R/W
00035 0
Clear Counter
(1: write to clear value)
Write
00036 1 Write
00037 0 Clear Overflow
(1: counter overflow,
auto set to 0 after read)
R/W
00038 1 R/W
00039 0 DI Latch Status
(1: DI latched,
0: write to clear latch)
R/W
00040 1 R/W
00101 0
Reset Historical
Maximum AI Value
Write
00102 1 Write
00103
Average
Channel 0~1
Write
00111 0
Reset Historical
Minimum AI Value
Write
00112 1 Write
00113
Average
Channel 0~1
Write
00131 0
High Alarm Flag
Read
00132 1 Read
00133
Average
Channel 0~1
Read
00141 0
Low Alarm Flag
Read
00142 1 Read
00143
Average
Channel 0~1
Read
Address 4X Channel Description Attribute
40211 Module Name 1 Read
40212 Module Name 2 Read
40221 All AI AI Channel Enable R/W
