Advantech WISE-4050/LAN User Manual

WISE-4000 User Manual 6
1.5 Switch
Note 1 After the position 1 of SW1 been changed, user need to power on the
module again to apply the operation mode
Note 2 SW2 is for WISE-4051, WISE-4050(/LAN), and WISE-4060(/LAN), all 4
channels have to be configured to dry contact or wet contact in the same
time, and both P1 and P2 have to be changed together
Note 3 SW3 is for WISE-4051 only, all 4 channels have to be configured to dry
contact or wet contact in the same time, and both P1 and P2 have to be
changed together
1.6 LED Definition
 WISE-4000 Wireless Series
 WISE-4051 Only
 WISE-4000/LAN Series
Switch Description Position ON (Default) OFF
SW1 Operation Mode
P1 Normal Mode Initial Mode
P2 N/A N/A
SW2
DI Type
(Ch0~3)
P1 Dry Contact Wet Contact
P2 Dry Contact Wet Contact
SW3
DI Type
(Ch4~7)
P1 Dry Contact Wet Contact
P2 Dry Contact Wet Contact
LED Color Indication Behavior
Status Green
Blink
2Hz: Wait for connection
0.5Hz: Network Connected
ON 30 Sec When enable LOCATE function.
Com Yellow Blink When TX/RX data in transmission
AP/Infra Green
ON Limited AP Mode
OFF Station Mode
Signal
Strength
Green
ON *4 Full Signal
ON *3 Good Signal
ON *2 Okay Signal
ON *1 Poor Signal
All OFF No Signal/ Limited AP Mode
LED Color Indication Behavior
Tx Yellow Blink RS-485 port is transmitting data
Rx Green Blink RS-485 port is receiving data
LED Color Indication Behavior
Status Green
Blink Module is normally at work. (1Hz)
ON 30 Sec When enable LOCATE function.
Com Yellow Blink When TX/RX data in transmission
Link Green ON Both ends of devices are connected
Speed Yellow ON/OFF
ON: 100 Mbps
OFF: Less than 10 Mbps
