123 WISE-4000 User Manual
Appendix B REST for WISE-4000 Series
Resource value definitions:
Field Abbreviation Data Type Property Description
Channel Number Ch Number R 0, 1, …: Digital input channel number.
Mode Md Number R
Digital input mode.
Signal Logic Status Stat Number R 1, 0: Input signal is Logic High or Low.
Channel Value Val Number R
DI measurement data
Start Counter Cnting Number RW
Start/Stop counter counting
Read
1 : counter is counting
0 : not counting
Write
1 : start counting
0 : stop counting
Clear Counter ClrCnt Number W 1 : Clear the counter value
Get/Clear Counter
Overflow or Latch Sta-
tus
OvLch Number RW
counter overflow or latch status
Read
1 : overflow/latch occurred.
0 : no overflow or latch
Write
0 : clear the overflow or latch status
0DI
1 Counter
2 LowToHighLatch
3 HighToLowLatch
4 Frequency
Input Mode Value Description
DI Logic Status of DI
Counter Counter Value
LowToHighLatch Logic status of DI
HighToLowLatch Logic status of DI
Frequency Frequency(unity 0.1 Hz)
