WISE-4000 User Manual 134
Maximum AI
Engineering data
HEg Number R
AI max. engineering data, the value is 1/1000
scale
For example,
1020010.2
Minimum AI
Raw Value
LVal Number R AI min. measurement data (Raw data)
Minimum AI
Engineering data
LEg Number R
AI min. engineering data, the value is 1/1000
scale
For example,
250 0.25
Channel Raw
Value After Scal-
ing
SVal Number R
0 ~ 65535 : AI measurement data (Raw data)
after scaling
Clear Maximum
AI Value
ClrH Number W 1 : Clear the Maximum AI value
Clear Minimum
AI Value
ClrL Number W 1 : Clear the Minimum AI value
Physical value
after scaling
PEg Number R
AI physical value after scaling, the value is 1/
1000 scale
For example:
150350'150.35
Mapping unit Uni String R
Unit for mapping value
Max. 32 characters
* AI Status (2 Registers)
Lower Register Higher Register
Bit Description Bit Description
0 Fail to Provide AI Value 0 DI triggered to Safety Value
1 Over Range 1 DI triggered to Startup Value
2 Under Range 2 Reserved
3 Open Circuit / Burnout 3 Reserved
4 Reserved 4 Reserved
5 Unavailable Channel Configuration 5 Reserved
6 Reserved 6 Reserved
7 ADC Initializing/Error 7 Reserved
8 Reserved 8 Reserved
9 Zero/Span Calibration Error 9 Reserved
10 Reserved 10 Reserved
11 Reserved 11 Reserved
12 Reserved 12 Reserved
13 Reserved 13 Reserved
14 Reserved 14 Reserved
15 Reserved 15 Reserved
To Next Page
