HV844-N 12.01 R.B. 599 51 31 28 EN
Knock out the axle using the enclosed punch. The drum lid can be removed. (see figure
4,5 and 6)
For the second drum lid repeat the process d).
Exchange of spring and softopening
a) Loosen the shackle in the middle:
- Mark the point with a punch and rebore the center punch mark with a 5 mm drill,
deburr the shackle (see figure 7 and 8)
