Care Of Your Machine
Step 2
25
Turn off the power switch and unplug
the machine before cleaning.
Do not dismantle the machine other
than as explained in this section.
Cleaning shuttle race
To dismantle the hook race
Shuttle race cover holder
Shuttle race cover
Shuttle
Shuttle race
a: Raise the needle to its highest
position and open the Shuttle cover
.
b: Open the hinged Latch of the
Bobbin Case and take it out of
the machine.
c: Open the Shuttle Race Cover
Holder .
d: Remove the Shuttle Race Cover .
e: Remove the Shuttle .
f: Clean the Shuttle Race with a
brush and soft dry cloth.
To oil the shuttle race
g: Before assembling the shuttle race,
oil the shuttle race using a few drops
of fine quality sewing machine oil .
Note: Use oil sparingly as over oiling
will cause it to leak onto your fabric.
