Care Of Your Machine
Step 2
To assemble the shuttle race
h: Hold the Shuttle by the center
pin and fit it carefully back into the
Shuttle Race , forming a perfect
circle with the shuttle driver.
i: Attach the Shuttle Race Cover
making sure that the bottom pin fits
into the notch.
j: Lock the Shuttle Race Cover Holders
by turning the holders back into
position.
k: Insert the Bobbin Case .
Step 3
Cleaning the feed dogs
a: Remove the needle and the presser
foot.
Remove the needle plate ste screws
and remove the Needle plate .
b: With a brush, clean out dust and lint
clogging on the feed dog teeth.
Replace the needle plate.
26
