85
EN
Connection Grounding screw Conductor
U1, V1, W1, cross section
U2, V2, W2
16 / 30A lug / M4 lug / M4 max. 6 mm
2
45A* M 6 M 6 max. 50 mm
2
60* / 100A* M 6 M 6 max. 50 mm
2
130 / 170A M 8 M 10 95 / 120 mm
2
280 A M 10 M 10 150 / 185 mm
2
350A M 10 M 10 185 mm
2
495A M 10 M 10 Cu 48x3; 2xø11
650A M 10 M 10 Cu 48x3; 2xø11
1000A M12 M12 Cu 60x10; 2xø14
1400A M12 M12 Cu 60x10; 2xø14
1500A M12 M12 Cu 60x10; 2xø14
In UL applications, use only 60°C or 60°C/75°C copper conductors (except for
control lines).
* In UL applications, use only 75°C copper conductors (except for control lines).
Screw Min. value Nom. value Max. value
M 2 0.22 0.25 0.28 (Phoenix terminals)
M 4 0.85 1.3 1.7
M 6 2.95 4.4 5.9
M 8 11.5 17 22.5
M 10 22 33 44
M 12 38 56 75
Torques in Nm
