AERMEC ANZ 020 - Technical Heating Data (No Accumulation); Heating Performance and Energy Indices; Electrical, Compressor, and Evaporator Specs; Dimensions and Sound Data

12
Ver. U.M. 0207 0257 0307 0417 0507 0807 0907 1007 1507 2007
Heating capacity
H kW 8,1 8,5 10,3 12,1 16,1 17,3 22,6 33,8 38,0 47,3
Input power
H kW 2,4 2,5 3,1 3,6 4,6 4,9 6,8 9,3 11,0 13,8
Water flow rate
H l/h 1390 1460 1770 2080 2770 2980 3890 5810 6540 8140
Pressure drop
H kPa674331,5442136314750
Energy indices
COP
H W/W 3,38 3,40 3,32 3,36 3,50 3,53 3,32 3,63 3,45 3,43
Electrical data
Power supply
° 3~ 400 V -50 Hz
FLA (1)
230 V A 18,0 17,5 23,8 26,8 n.a. n.a. n.a. n.a. n.a. n.a.
400 V A 6,4 7,7 9,2 11,3 9,8 13,2 17,0 22,0 29,5 35,0
Nominal input current
230 V A 12,5 11,7 15,8 16,4 n.a. n.a. n.a. n.a. n.a. n.a.
400 V A 4,4 4,5 5,6 5,7 9,3 10,2 13,5 18,4 20,3 27,1
LRA (2)
230 V A 75,0 78,0 99,0 113,0 n.a. n.a. n.a. n.a. n.a. n.a.
400 V A 32,0 40,0 46,0 52,0 65,0 77,0 100,0 130,0 170,0 202,0
Compressors
type
H scroll
Quantity
H n°1111111111
Fans
type
H Axial
Quantity
H n°11122
22222
Air flow rate
Hm
3
/h
2500 3300 3450 5300 7000 6700 6450 13450 12400 12000
Sound data
Sound pressure (3)
° dB(A) 33 40 40 37 41 41 40 48 49 50
Evaporator
type
H Plates
Quantity
H n°1111111111
Attachments
IN ø 1”1”1”1”1”1”1”1”1”1”
OUT ø 1” 1” 1” 1” 1” 1” 1” 1” 1” 1”
Dimensions
Height
H
mm
850 850 1000 1250 1250 1250 1580 1345 1345 1345
Width
H
mm
900 900 900 1120 1120 1120 1167 1750 1750 1750
Length
H
mm
352 352 352 435 435 435 555 750 750 750
Weight
H
kg
78 81 85 128 129 137 252 314 353 394
(1) FLA = Maximum input current
(2) LRA = Starting current
(3) = Measured in free field at ten metres
away with direction factor Q=2
anz
Technical heating data (versions without accumulation)
Heating:
Water inlet temperature 40°C
Water outlet temperature 45°C
outside air temperature
7 °C (B.S)
6 °C (B.U)
