13
Ver. U.M. 0207 0257 0307 0417 0507 0807 0907 1007 1507 2007
Cooling capacity
HA kW 6,2 6,7 8,7 10,6 14,3 16,5 20,9 29,4 34,3 41,6
Input power
HA kW 2,6 2,7 3,5 3,8 4,9 5,6 7,1 10,0 12,2 14,6
Water flow rate
HA l/h 1070 1150 1500 1820 2460 2840 3590 5060 5900 7160
Expansion tank capacity
HAl 2225555888
Accumulation tank capacity
HA l 25253535757575145145145
Pump speed
HAn°3333333111
Useful system head
H kPa 70 66 66 60 61 58 50 68 68 69
Energy indices
EER
HA W/W 2,38 2,48 2,49 2,79 2,92 2,95 2,94 2,94 2,81 2,85
Electrical data
Power supply
° 3~ 400 V -50 Hz
FLA (1)
230 V A 18,7 18,2 24,5 27,5 n.a. n.a. n.a. n.a. n.a. n.a.
400 V A 7,1 8,4 9,9 12,0 10,6 13,2 17,0 22,0 29,5 37,0
Nominal input current
230 V A 13,9 12,9 18,4 19,3 n.a. n.a. n.a. n.a. n.a. n.a.
400 V A 5,6 6,1 7,6 8,3 10,4 11,3 15,1 21,1 23,3 28,8
LRA (2)
230 V A 76,0 78,0 100,0 115,0 n.a. n.a. n.a. n.a. n.a. n.a.
400 V A 33,0 41,0 48,0 54,0 66,0 78,0 101,0 132,0 172,0 203,0
Compressors
type
° scroll
Quantity
° n°1111111111
Fans
type
° Axial
Quantity
° n°11122
22222
Air flow rate
°m
3
/h
2500 3300 3450 5300 7000 6700 6450 13450 12400 12000
Sound data
Sound pressure (3)
° dB(A) 33 40 40 37 41 41 40 48 49 50
Evaporator
type
° Plates
Quantity
° n°1111111111
Attachments
IN ø 1”1”1”1”1”1/41”1/41”1/41”1/21”1/21”1/2
OUTø 1”1”1”1”1”1/41”1/41”1/41”1/41”1/41”1/4
Dimensions
Height
HA
mm
864 864 1014 1250 1280 1280 1580 1345 1345 1345
Width
HA
mm
112 0 112 0 112 0 112 0 116 7 116 7 116 7 17 5 0 17 5 0 17 5 0
Length
HA
mm
435 435 435 435 555 555 555 750 750 750
Weight
HA
kg
113 117 125 154 189 195 277 376 430 469
anz
Technical cooling data (versions with accumulation)
Cooling:
Water inlet temperature 12°C
Water outlet temperature 7°C
outside air temp. 35 °C
(1) FLA = Maximum input current
(2) LRA = Starting current
(3) = Measured in free field at ten metres
away with direction factor Q=2
