AERMEC ANZ 020 - Heating Capacity and Input Power Adjustments; Correction Diagram for Heating Performance; Applying Heating Correction Coefficients

17
-14 -12 -4 -2 4 8 12 200 2 6 10 14 16 18-6-8-10-16
0,40
0,60
0,80
1,00
1,20
1,40
0,30
0,50
0,70
0,90
1,10
1,30
1,50
0,70
0,80
0,90
1,00
1,10
1,20
1,30
1,40
0,50
0,60
40
45
50
35
40
45
50
35
30
30
Heating capacity and input power
Key::
Ct = Heating capacity correction coefficient
Ca = Input power correction coefficient
Ca
The refrigerating capacity yielded and the
input electrical capacity in conditions
other than rated conditions are obtained
by multiplying the rated values (Pf, Pa)
Ct
Outside air temperature °C (B.U.)
fig. 03
by the respective corrective coefficients
(Cft, Cpa).
The diagram makes it possible
to obtain the correction coefficients;
corresponding to each curve the
temperature of the hot processed water
referred to, assuming a difference in water
temperature between the input and output
of the condenser equal to 5°C, is reported.
Correction coefficient for H versions (heating functioning)
