AERMEC ANZ 020 - Technical Heating Data (With Accumulation); Heating Performance and Hydraulic Capacities; Electrical, Compressor, and Evaporator Specs; Dimensions and Sound Data

14
Ver. U.M. 0207 0257 0307 0417 0507 0807 0907 1007 1507 2007
Heating capacity
HA kW 8,1 8,5 10,3 12,1 16,1 17,3 22,6 33,8 38,0 47,3
Input power
HA kW 2,6 2,7 3,3 3,8 4,9 5,2 7,1 9,9 11,7 14,5
Water flow rate
HA l/h 1390 1460 1770 2080 2770 2980 3890 5810 6540 8140
Expansion tank capacity
HAl 2225555888
Accumulation tank capacity
HA l 25253535757575145145145
Pump speed
HAn°3333333111
Energy indices
COP
H W/W 3,12 3,15 3,12 3,18 3,29 3,33 3,18 3,41 3,25 3,26
Electrical data
Power supply
° 3~ 400 V -50 Hz
FLA (1)
230 V A 18,7 18,2 24,5 27,5 n.a. n.a. n.a. n.a. n.a. n.a.
400 V A 7,1 8,4 9,9 12,0 10,6 13,2 17,0 22,0 29,5 37,0
Nominal input current
230 V A 13,3 12,2 16,7 18,5 n.a. n.a. n.a. n.a. n.a. n.a.
400 V A 5,7 5,8 7,3 8,1 10,6 11,3 15,0 20,1 22,3 28,5
LRA (2)
230 V A 76,0 78,0 100,0 115,0 n.a. n.a. n.a. n.a. n.a. n.a.
400 V A 33,0 41,0 48,0 54,0 66,0 78,0 101,0 132,0 172,0 203,0
Compressors
type
H scroll
Quantity
H n°1111111111
Fans
type
HA Axial
Quantity
HAn°11122
22222
Air flow rate
HA m
3
/h
2500 3300 3450 5300 7000 6700 6450 13450 12400 12000
Sound data
Sound pressure (4)
HA dB(A)3340403741 4140484950
Evaporator
type
HA Plates
Quantity
HAn°1111111111
Attachments
IN ø 1” 1” 1” 1” 1”1/4 1”1/4 1”1/4 1”1/2 1”1/2 1”1/2
OUT ø 1” 1” 1” 1” 1”1/4 1”1/4 1”1/4 1”1/4 1”1/4 1”1/4
Dimensions
Height
HA
mm
864 864 1014 1250 1280 1280 1580 1345 1345 1345
Width
HA
mm
112 0 112 0 112 0 112 0 116 7 116 7 116 7 175 0 17 5 0 175 0
Length
HA
mm
435 435 435 435 555 555 555 750 750 750
Weight
HA
kg
113 117 125 154 189 195 277 376 430 469
anz
Technical heating data (versions with accumulation)
(1) FLA = Maximum input current
(2) LRA = Starting current
(3) = Measured in free field at ten metres
away with direction factor Q=2
Heating:
Water inlet temperature 40°C
Water outlet temperature 45°C
outside air temperature
7 °C (B.S)
6 °C (B.U)
