Size data ANZ 0417 - 0507 - 0807
• ANZ 0417H
435 1.120
1.250
105
230 280
70
715 466
Out
In
Holes for electrical connections •
• Male plumbing
attachment diam 1”
Microchiller
•
435 1.120
1.250
105
230 280
70
715 466
Out
In
• Male plumbing
attachment diam 1”
Microchiller
•
• ANZ 050HA - 080HA
• ANZ 0417HA - 0417HK - 0417HJ
435 1.120
1.250
431,5
108
80 400
450
45
Out
In
• Female plumbing
attachment diam 1”
Microchiller
•
555
1.167
1.280
In
Out
450
400
46
210 130
• Female plumbing
attachment diam 1”1/4
Microchiller
•
Holes for
electrical
connections
•
• ANZ 0507H - 080H
