AERMEC ANZ 020 - Size Data (ANZ 0907-2007); ANZ 0907 H and HA Dimensions; ANZ 1007 H;1507 H;2007 H and HA Dimensions

29
555 1.167
1.580
325
230 280
70
758 466
In
Out
Holes for electrical connections •
•
Male plumbing attachment
diam
Ø 1”
Microchiller
•
Size data ANZ 0907 - 1007 - 1507 - 2007
• ANZ 0907H
750 1.750
1.345
340
466400
420
360
Out
In
Male plumbing attachment diam 1”
Microchiller
•
• ANZ 1007HA - 1507HA - 2007HA
• ANZ 0907HA
555
1.167
1.280
In
Out
450
400
46
210 130
• Female plumbing
attachment diam
1”1/4
Microchiller
•
750 1.750
1.345
57
360
420
170 130
60
Out
In
Female plumbing
attachment diam
1”1/2
Microchiller
•
• ANZ 1007H - 1507H - 2007H
Holes for
electrical
connections
•
Female plumbing attachment diam 1”1/4 •
1.580
