7Aermec cod. 5806715_00 12.01
NRP 0200-0750
EN
2. CONFIGURATOR
Description
1,2,3 NRP
4,5,6 SIZE
020 - 024 - 028 - 030 - 033 - 035 - 050 - 055 - 060 - 065 - 070 - 075
7 COMPRESSOR
0
8 VERSION
A High efficiency
E Silenced high efficiency
9 TYPE OF SYSTEM
2 Two pipes
4 Four pipes
10 COILS
° Aluminium
R Copper
S Tinned copper
V In painted aluminium-copper (epoxy powders)
11 FANS
° Standard
M Increased (only 020-035)
J Larger inverters (only available from 050 to 075)
12 POWER SUPPLY
° 400V/3N/50Hz with magnet circuit breakers
1 230V3 50Hz with magnet circuit breakers
2 500V/3/50Hz with magnet circuit breakers
13,14 SYSTEM SIDE HYDRONIC KIT
00 Without storage tank
01 Storage tank | low static pressure pump | system side
02 Storage tank | low static pressure pump | reserve pump | system side
03 Storage tank | high static pressure pump | system side
04 Storage tank | high static pressure pump | reserve pump | system side
05 Storage tank with holes for integrative resistance | low static pressure pump | system side
06 Storage tank with holes for integrative resistance | low static pressure pump | reserve pump | system side
07 Storage tank with holes for integrative resistance | high static pressure pump | system side
08 Storage tank with holes for integrative resistance | high static pressure pump | reserve pump | system side
P1 Low static pressure pump | system side
P2 Low static pressure pump | reserve pump | system side
P3 High static pressure pump | system side
P4 High static pressure pump | reserve pump | system side
15,16 DHW SIDE HYDRONIC KIT
2
00 Without Pumps
R1 Low static pressure pump | DHW side
R2 Low static pressure pump | reserve pump | DHW side
R3 High static pressure pump | DHW side
R4 High static pressure pump | reserve pump | DHW side
POSSIBLE CONFIGURATIONS BETWEEN HYDRONIC KITS
recovery hydronic unit
system hydronic unit
° R1R2R3R4
° ok ok ok ok ok
01 ok nd nd nd nd
02 ok nd nd nd nd
03 ok nd nd nd nd
04 ok nd nd nd nd
05 ok nd nd nd nd
06 ok nd nd nd nd
07 ok nd nd nd nd
08 ok nd nd nd nd
P1 ok ok ok ok ok
P2 ok ok ok ok ok
P3 ok ok ok ok ok
P4 ok ok ok ok ok
Description 0200 0240 0280 0300 0330 0350 0500 0550 0600 0650 0700 0750
11 FANS
° ••••••••••••
M ••••••NoNoNoNoNono
J NoNoNoNoNoNo••••••
12 POWER SUPPLY
° 400V/3N/50Hz ••••••••••••
1 230V/3/50Hz No No •••••••••No
2 500V/3/50Hz No No No No No No No
1
nd = not available
2 DHW SIDE/SYSTEM SIDE
DHW side, production of domestic hot
water, in 2-pipe systems.
System side, production of hot water,
in 4-pipe systems.
