AERMEC VXT - MAIN menu - PAGE 10; MAIN menu - PAGE 11; MAIN menu - PAGE 12

39
MAIN menu - PAGE 12
Visualisation on unit display Index Display/Parameter
A DHW temperature: Indicates the temperature of the water
produced for DHW use.
B Page index: Identifies the menu and the corresponding page:
P = MAIN menu
S = SET-POINT menu
M = MAINTENANCE TECHNICIAN menu (Blocked)
C = MANUFACTURER’S menu (Blocked)
CK = CLOCK menu
The number associated to one of the previous codes, indicates
the page of the menu indicated.
C Cylinder inlet water temperature: Indicates the water inlet
temperature at the heat exchanger.
D Cylinder outlet water temperature: Indicates the water outlet
temperature at the cylinder.
E Cylinder Delta T: Indicates the temperature difference betwe-
en inlet and outlet
MAIN menu - PAGE 11
Visualisation on unit display Index Display/Parameter
A System water temperature: Indicates the temperature of the
water produced for the system.
B Page index: Identifies the menu and the corresponding page:
P = MAIN menu
S = SET-POINT menu
M = MAINTENANCE TECHNICIAN menu (Blocked)
C = MANUFACTURER’S menu (Blocked)
CK = CLOCK menu
The number associated to one of the previous codes, indicates
the page of the menu indicated.
C Inlet water temperature: Indicates the water inlet temperatu-
re at the heat exchanger.
D Outlet water temperature: Indicates the water outlet tempe-
rature at the heat exchanger
E System Delta T: Indicates the temperature difference betwe-
en inlet and outlet
MAIN menu - PAGE 10
Visualisation on unit display Index Display/Parameter
A
Compressor 1 ON: Indicates whether compressor 1 is wor-
king, i.e. if the unit is working to satisfy a call.
B Page index: Identifies the menu and the corresponding page:
P = MAIN menu
S = SET-POINT menu
M = MAINTENANCE TECHNICIAN menu (Blocked)
C = MANUFACTURER’S menu (Blocked)
CK = CLOCK menu
The number associated to one of the previous codes, indicates
the page of the menu indicated.
C System pump: Indicates whether the system pump is active.
D DHW pump: Indicates whether the DHW pump is active.
Parameters that can be modified by the user
Sanitary water P12
Sanitary tank 49.5 C
Outlet 55.0 C
DT 05.5 C
Compressor 1 On P10
Plant pump
Sanitary pump 000%
A
B
C
DD
Plant water P11
Inlet 30.0 C
Outlet 35.0 C
DT 05.0 C
A B
C
D
E
A B
C
D
E
