AERMEC VXT - MAIN menu - PAGE 13; MAIN menu - PAGE 24

40
MAIN menu - PAGE 13
Visualisation on unit display Index Display/Parameter
A
Temperature probes for external air and geothermy:
Indicates the temperatures of the external air and the con-
denser inlet (which can indicate the geothermy probe water
temperature or the water sheet temperature, on the basis of
the type of system envisioned).
B Page index: Identifies the menu and the corresponding page:
P = MAIN menu
S = SET-POINT menu
M = MAINTENANCE TECHNICIAN menu (Blocked)
C = MANUFACTURER’S menu (Blocked)
CK = CLOCK menu
The number associated to one of the previous codes, indicates
the page of the menu indicated.
C External air temperature: Indicates the temperature of the
external air. This temperature will be used to calculate the
compensated work set-point if this function has been activa-
ted; otherwise this data will not cause any modification on
system functioning, however keeping the display of this data.
D Condenser outlet water temperature: Indicates the tempera-
ture of the condenser inlet water (which could be outlet from
the geothermy probe or water sheet, on the basis of the type
of system realised)
MAIN menu - PAGE 24
Visualisation on unit display Index Display/Parameter
A Configurable outlet: Displays the status (Activated/
Deactivated) of the outlet that can be configured by the instal-
ler, which can represent:
• Heat recovery
• Summer/winter
• Alarm output
B Page index: Identifies the menu and the corresponding page:
P = MAIN menu
S = SET-POINT menu
M = MAINTENANCE TECHNICIAN menu (Blocked)
C = MANUFACTURER’S menu (Blocked)
CK = CLOCK menu
The number associated to one of the previous codes, indicates
the page of the menu indicated.
Probes temperat. P13
external air 30.0C
codens. outlet 32.9C
P24
Recupator
A B
D
C
A B
