MAINTENANCE MANUAL
IFR 6000
2-TABLE OF CONTENTS
Page 2
Aug 1/06
Title Chapter/Section/Subject Page
D. Verification (cont)
(19) XPDR Measurement, Reply Accuracy, Mode S 2-2-3 33
(20) Altitude Encoder 2-2-3 36
(21) Generate Video 2-2-3 37
(22) ADSB Receive DF17/DF20 Squitter Period 2-2-3 38
(23) ADSB Generate DF17/DF18 Squitter Period 2-2-3 42
(24) TIS Receive 2-2-3 45
(25) TCAS Reply Pulse Characteristics 2-2-3 47
(26) TCAS Reply Pulse Amplitdues 2-2-3 50
(27) TCAS Squitter Period 2-2-3 52
(28) TCAS Percent Reply 2-2-3 53
(29) TCAS Reply Delay and Range 2-2-3 55
(30) TCAS Mode S Reply 2-2-3 58
(31) TCAS Measurement/Interrogation Frequency 2-2-3 60
(32) RF Power Measurement 2-2-3 62
E. Verification Data Sheet 2-2-3 67
F. Calibration 2-2-3 77
(1) Test Setup 2-2-3 77
(2) RTC Calibration 2-2-3 78
(3) TCXO Calibration 2-2-3 79
(4) Video Calibration 2-2-3 80
(5) TX Level Calibration 2-2-3 81
(6) RX Level Calibration 2-2-3 82
4. Assembly Drawings 2-2-4 1
SECTION 3 - DISASSEMBLY/REASSEMBLY 2-3
1. Disassembly 2-3-1 1
A. General 2-3-1 1
B. Preliminary Considerations 2-3-1 1
(1) Tools Required 2-3-1 1
(2) Disassembly Precautions 2-3-1 1
(3) ESD 2-3-1 2
(4) EMC and Safety Compliance 2-3-1 2
C. Procedures 2-3-1 3
(1) Battery 2-3-1 3
(2) Fuse 2-3-1 5
(3) Case Assy 2-3-1 7
(4) Power Supply PCB Assy 2-3-1 9
(5) RF Assy 2-3-1 10
(6) Processor PCB Assy 2-3-1 12
(7) Multi-Function PCB Assy 2-3-1 13
(8) Keypad PCB Assy 2-3-1 15
(9) LCD PCB Assy 2-3-1 16
(10) LCD PCB Assy 2-3-1 18
2. Reassembly 2-3-2 1
A. General 2-3-2 1
B. Preliminary Considerations 2-3-2 1
(1) Tools Required 2-3-2 1
(2) Reassembly Precautions 2-3-2 1
(3) ESD 2-3-2 1
(4) EMC and Safety Compliance 2-3-2 1
