MAINTENANCE MANUAL
IFR 6000
2-2-3
Page 59
Aug 1/06
STEP PROCEDURE
10. Set up the UUT in SETUP-TCAS menu as follows:
ANT Range: 250 ft
ANT Height: 1 ft
Squitters: OFF
UUT ADDRESS: AUTO
MANUAL AA: A92493
11. Press the TCAS key on the UUT.
12. Set the TCAS screen as follows:
TCAS Type: TCAS II (
Intruder Type: MODE S
% Reply: 100
Range Start: 0.00 nm
Range Rate: 0 kts
ALT START: 1000ft
ALT RATE: 0fpm
13. Press the RUN TEST Soft Key on both IFR 6000 and the UUT.
14. Verify that both units are replying and the IFR-6000 displays the following
information replied from the UUT:
DF=0, VS=0, CC=0, SL=0, RI=0, AC=1000 and AA=A92493
15. Press the STOP TEST Soft Key on the IFR 6000.
16. On the IFR 6000, press the NEXT TEST Soft Key till the TCAS DIAG-DF16
screen is displayed.
17. Press the RUN TEST Soft Key on the IFR 6000.
18. Verify that both units are replying and the IFR-6000 displays the following
information replied from the UUT:
19. DF=16, VS=0, SL=0, RI=3, MV=30000000000000, AC=1000ft and AA=A92493
20. Press the STOP TEST Soft Key on the IFR 6000.
21. On the IFR 6000, press the PREV TEST Soft Key till the TCAS DIAG-DF11
screen is displayed.
22. On the IFR-6000, set the FORMAT 11address to FFFFFF.
23. Press the RUN TEST Soft Key on the IFR 6000.
24. Verify that both units are replying and the IFR-6000 displays the following
information replied from the UUT:
DF=11, CA=0, and AA=A92493
25. Press the STOP TEST Soft Key on both IFR-6000 and the UUT.
