MAINTENANCE MANUAL
IFR 6000
2-2-3
Page 42
Aug 1/06
(23) ADSB Generate DF17 and DF18 – Squitter Period
TEST EQUIPMENT: IFR 6000 with opt. 3
Computer with Tera Term software
6000 Breakout Box
VERIFICATION FAILURE: If any step in this procedure fails or is out of tolerance,
this indicates a failure in the Test Set. Refer to
Troubleshooting for corrective action.
STEP PROCEDURE
1. Connect the ANT port of the IFR-6000 to the ANT port of the UUT.
2. On the IFR 6000, press the SETUP key to display the SETUP-XPDR screen.
3. Verify the RF PORT shows ANTENNA. If necessary, change it to ANTENNA and
select BOTTOM ANTENNA.
4. Connect the 6000 Breakout Box to the IFR 6000 and connect the computer to
the Breakout Box via a RS-232 cable.
5. Using a terminal program, send to the IFR-6000 the RCI command “I:ADSB:MTL
SKIP” to skip MTL.
6. Set up the SETUP-XPDR screen as follows:
BOTTOM ANT: RANGE 100ft., HEIGHT 1ft.
UUT ADDRRESS: MANUAL
AA MANUAL: A92492
CHECK CAP: YES
7. Press the ADSB SETUP key on the IFR 6000 to display the SETUP-ADSB
screen.
8. On the SETUP-ADSB screen, set up the IFR 6000 as follows:
POS DECODE: GLOBAL
LAT: 0 0 0 N
LONG: 0 0 0 E
ADSB GEN: DF17
ADSB MON: DF17
GICB: DF20
9. On the IFR 6000, press the XPDR Key until the ADS-B/GICB Main screen is
displayed.
10. Press the ADSB MON Soft Key to display the ADS-B MON DF17 screen.
11. Press the BDS DATA Soft Key to display the ADS-B MON BDS 0,5 screen.
12. On the UUT, press the SETUP key to display the SETUP-XPDR screen.
13. Verify the RF PORT shows ANTENNA. If necessary, change it to ANTENNA and
select BOTTOM ANTENNA.
To Next Page
