MAINTENANCE MANUAL
IFR 6000
2-2-3
Page 39
Aug 1/06
STEP PROCEDURE
4. Verify the RF PORT shows ANTENNA. If necessary, change it to ANTENNA and
select BOTTOM ANTENNA.
5. Set up the SETUP-XPDR screen as follows:
BOTTOM ANT: RANGE 12ft., HEIGHT 1ft.
UUT ADDRRESS: MANUAL A92492
CHECK CAP: YES
6. Press the ADSB SETUP key to display the SETUP-ADSB screen.
7. In SETUP-ADSB screen, set up the UUT as follows:
POS DECODE : GLOBAL
LAT: 0 0 0 N
LONG : 0 0 0 E
ADSB GEN: DF17
ADSB MON: DF17
GICB: DF20
8. Connect the computer COMM port to the RS-232 connector on the Breakout Box.
9. Using the Tera Term terminal program, send the ‘MTL_Disable’ file, found on the
IFR 6000 maintenance manual CD, to the UUT to override the MTL function of
the unit. Press the LOCAL Soft Key to return unit to local mode.
10. Connect ARB #2 to the computer and start the Intuilink software. Send the file
“DF4.wvf” to ARB #2 memory #1 and “DF17.wvf” to volatile memory on ARB #2.
Both files can be found on the IFR 6000 maintenance manual CD. Enter the
required Frequency and Output voltage from table 22.1 for the DF4 waveform
when prompted.
11. Verify ARB #1 and ARB #2 are set as:
Function ARB #1 ARB #2
Frequency 1kHz 15.625kHz
Output Pulse, 4Vpp, 0V Offset Arbitrary, 5V high, 0V
Trigger External, positive slope External, negative slope
Mode Burst, 1 cycle Burst, 1 cycle
Impedance High Z 50 Ohm
12. Set pulse width on ARB #1 to 132.75 µs.
13. Press the XPDR button until the ADS-B/GCIB MAIN screen is displayed.
14. Press the ADS-B MON Soft Key to DISPLAY THE ADS-B MON DF17 screen.
15. Select the ADSB MON test #1 (0,5 AIRBORNE POS) and press the BDS DATA
Soft Key to display the ADS-B MON BDS 0,5 screen.
16. Press the RUN TEST Soft Key
17. Wait until the UUT is showing replies and select the DF17 waveform as an
output from volatile memory on ARB #2 while test is running and set ARB #2
frequency to 8.3333kHz.
