MAINTENANCE MANUAL
IFR 6000
2-2-3
Page 44
Aug 1/06
STEP PROCEDURE
30. Press the XPDR Key on the IFR 6000 to return to the ADSB MON test #1 (0,5
AIRBORNE POS).
31. On the UUT, press the SETUP button and then the ADSB SETUP Soft Key to
display the SETUP-ADSB screen.
32. Change the ADSB GEN setting to DF18.
33. Press the XPDR Key on the UUT to return to the ADS-B GEN BDS 0,5 screen.
34. Set the fields as follows:
TYPE: 10
DF18 AA: A92492
PERIOD: 0.50 s
BARO PRES ALT: 2000 ft
35. On the UUT, press the RUN TEST Soft Key.
36. On the IFR-6000, press the RUN TEST Soft Key).
37. Ensure that the DF18 message from the UUT is decoded correctly on the IFR-
6000 by verifying the following information is present on the IFR 6000:
BDS =: 0,5 AIRBORNE POS
TYPE: 10
ME=: 500F8400000000
BARO PRES ALT: 2000 ft
38. Verify that the PERIOD equals 0.5 sec. ± 0.2 sec.
39. On the UUT, change the PERIOD to 1.0 and 5.0 sec. respectively.
40. At each setting, verify the PERIOD displayed on the IFR-6000 equals setting ±
0.2 sec.
41. Press the STOP TEST Soft Key on both UUT and the IFR-6000.
