MAINTENANCE MANUAL
IFR 6000
2-2-3
Page 43
Aug 1/06
STEP PROCEDURE
14. Set up the SETUP-XPDR screen as follows:
BOTTOM ANT: RANGE 100ft., HEIGHT 1ft.
UUT ADDRRESS: MANUAL
AA MANUAL: A92492
CHECK CAP: YES
15. Press the ADSB SETUP key to display the SETUP-ADSB screen.
16. On the SETUP-ADSB screen, set up the UUT as follows:
POS DECODE: GLOBAL
LAT: 0 0 0 N
LONG: 0 0 0 E
ADSB GEN: DF17
ADSB MON: DF17
GICB: DF20
17. On the UUT, press the XPDR Key until the ADS-B/GICB Main screen is
displayed.
18. ress the ADSB GEN Soft Key to display the ADS_B GEN DF17 screen.
19. Press the BDS DATA Soft Key to display the ADS-B GEN BDS 0,5 screen.
20. Set the ADS-B GEN BDS 0,5 screen. as follows:
TYPE: 9
DF17 AA: A92492
PERIOD: 0.50 s
BARO PRES ALT: 1000 ft
21. On the IFR-6000, press the RUN TEST Soft Key to the run ADSB MON test #1
(0,5 AIRBORNE POS).
22. On the UUT, press the BDS ON Soft Key and then the RUN TEST Soft Key to run
ADS-B GEN BDS 0,5.
23. Ensure that the DF17 message from the UUT is decoded correctly on the IFR-
6000 by verifying the following information is present on the IFR 6000:
BDS =: 0,5 AIRBORNE POS
TYPE: 9
ME=: 480B0400000000
BARO PRES ALT: 1000 ft
24. Verify that the PERIOD equals 0.5 sec. ± 0.2 sec.
25. On the UUT, change the PERIOD to 1.0 and 5.0 sec. respectively.
26. At each setting, verify the PERIOD displayed on the IFR-6000 equals setting ±
0.2 sec.
27. Press the STOP TEST Soft Key on both UUT and the IFR-6000.
28. On the IFR 6000, press the SETUP button and then the ADSB SETUP Soft Key
to display the SETUP-ADSB screen.
29. Change the ADSB MON setting to DF18.
To Next Page
