MAINTENANCE MANUAL
IFR 6000
2-2-3
Page 3
Aug 1/06
(1) Calibration/Verification Schedule
The Calibration/Verification Procedures should be performed as a result of one or
more of the following conditions:
O Failure to Meet Specifications
If, during the course of normal operation, the Test Set or any major function
thereof fails to meet the performance specifications according to Appendix F, the
Calibration/Verification Procedures should be performed.
If any failure occurs during performance of the Verification Procedures, the user is
instructed as to the pertinent Calibration Procedure or hardware failure associated
with the failure.
O Module/Assembly Replacement
If one or more of the Test Set assemblies are replaced, the Calibration Procedures
should be performed.
O Annual Calibration/Verification
Aeroflex recommends an annual Calibration/Verification on the Test Set to maintain
proper testing standards.
(2) Controls, Connectors and Indicators
Refer to Appendix E for location of the Test Set Controls, Connectors and Indicators.
(3) Test Record
Verification Data Sheets are provided for recording the results obtained while
performing the Verification Procedures.
NOTE: It is recommended the technician reproduce copies of the Verification Data
Sheets, rather than use copies in this manual.
B. Precautions
The Calibration and Verification Procedures are performed with the Test Set Covers in
place. No internal adjustments or probing points are required.
C. Requirements
(1) Performance
It is strongly recommended that personnel thoroughly read and understand all steps of
the procedures prior to performing each procedure. Knowledge of external test
equipment connections and operation is also recommended.
(2) Test Equipment
Appendix B contains a list of test equipment suitable for performing any procedure
contained in this manual. Other equipment meeting specifications listed in Appendix B
may be substituted in place of recommended models.
NOTE: For certain procedures in this manual, the equipment listed in Appendix B
may exceed minimum required specifications.
(3) Disassembly
No disassembly is required to perform the Calibration and Verification Procedures.
(4) Environment
For best results, environmental conditions should be identical to the conditions at the
normal operating location.
