MAINTENANCE MANUAL
IFR 6000
2-2-3
Page 57
Aug 1/06
STEP PROCEDURE
24. Verify spacing between the first SPR pulse of interrogation and the first pulse of
reply (P1) equals 127.49µS ± 0.05µS.
25. Press the STOP TEST Soft Key on both IFR 6000 and the UUT.
26. n the IFR 6000, press the NEXT TEST Soft Key till the ATCRBS MODE C screen
is displayed:
27. Change the UUT TCAS screen setup as follows:
TCAS Type: TCAS I
Intruder Type: ATCRBS
Range Start: 5 nm
28. Press the RUN TEST Soft Key on both IFR 6000 and the UUT.
29. Verify the range delay is 5.0 nm ± 0.02 nm (64.286µS ± 247nS).
30. Press the STOP TEST Soft Key on both IFR 6000 and the UUT.
To Next Page
