MAINTENANCE MANUAL
IFR 6000
2-2-3
Page 61
Aug 1/06
STEP PROCEDURE
6. On the UUT, press the TCAS and then the SETUP key to display the SETUP-
TCAS screen.
7. Verify the RF PORT shows ANTENNA. If necessary, change it to ANTENNA.
8. Set up the UUT in SETUP-TCAS menu as follows:
ANT Range: 250 ft
ANT Height: 1 ft
Squitters: OFF
UUT ADDRESS: AUTO
9. Press the TCAS key on the UUT.
10. Set the TCAS screen as follows
TCAS Type: TCAS I
Intruder Type: ATCRBS
% Reply: 100
Range Start: 0.35 nm
Range Rate: 0 kts
ALT Rate: 0 fpm
11. Move cable from the frequency counter to the UUT ANT port.
12. Press the RUN TEST Soft Key on the UUT.
13. On the ATC-1400A, set frequency (in MHz) from 1029.90 to 1030.10, step = 50
kHz respectively.
14. At each setting, verify that the frequency displayed on the UUT equals Recorded
Freq. ± 10 kHz.
15. Press the STOP TEST Soft Key.
