AFi LOREENA - Page 56

Originale Instructions- Rev.1.3 User Maunal– Loreena 54/ 68
Maximum Radius :
194 mm
Included :
Part number :
NU-TXDW4
Description:
Stainless Steel Extractor & Neoprene
pad (Set of 4)
(***)The radius is the distance between the rotor shaft and the bottom of the microplate carrier when the carrier is
spinning in a horizontal position (during centrifugation)
Microplate carrier lid
Picture not available
Part number :
NU-LXDW4
Description:
Lid for microplate carrier (Set of 2)
Extractor & pad
Part number :
NU-TXDW4
Description:
Stainless Steel Extractor & Neoprene
pad (Set of 4)
Configurations:
Loadings
Each bucket must be loaded evenly.
Allowed:
Forbidden:
Loading the rotor
The rotor must be loaded evenly.
Allowed:
Forbidden:
Note : A message appears when choosRX1000 rotor.
2x NU-B1000 loaded buckets
(inserts & loaded tubes)
2 NU-B1000 buckets
With empty inserts.
2xNU-B1000
chargées
(portoirs & tubes
pleins)
2 nacelles NU-
BXDW4 chargés
2 nacelles NU-B1000
loaded buckets
(inserts & loaded tubes)
2xNU-B1000 empty
buckets (ex: without
insert)
2xNU-B1000 loaded buckets
(inserts & loaded tubes)
2xNU-BXDW4 empty
buckets (ex: without insert)
Symmetrical loading
Asymmetrical loading
Incomplete loading
