2.5.4 Connecting Booms ON
Connect the booms on cable to the main computer (platinum console). Position the switch so that when the
dump handle is used the switch will turn on and off. If a switch is used to turn the spray on and off, we
recommend you remove the switch provided and wire the cable up to another switch to indicate when the
spray is on and off. The Main Computer recognizes a simple opening and closing of the two wires in the
booms on cable to indicate spray on and off. At no time, should there be any voltage applied to these two
wires, this will result in damage to the Main Computer (console).
