AG-NAV Platinum - Table of Contents

AG-NAV 1-800-99 AGNAV
5
Table of Contents
1. Getting Started………………………………………………….. 6-10
1.1 Getting Familiar with the Platinum System
1.1.1 Platinum console
1.2 Installation standards / responsibility
1.3 Reference Documents
1.4 Component description with weight and location
1.5 Before Installation
1.6 Installation Plan
1.7 Tools required
2. Installing the platinum components…………………………… 10-41
2.1 Platinum Installation
2.1.1 Flush mount bracket
2.1.2 Low profile mount Bracket
2.1.3 Mounting Plate Bracket
2.1.4 Adjustable Mounting Bracket
2.1.5 Ram Mount Bracket
2.2 GPS receiver Installation
2.3 Guidance Installation
2.4 GPS Antenna Installation
2.5 Cables and Electrical Connections
2.5.1 Breaker
2.5.2 Connecting Power cable
2.5.3 Connecting Remote Switch
2.5.4 Connecting Booms ON
2.5.5 Connecting Indicator Cable
2.5.6 Connecting Antenna Cable
2.5.7 Connecting GPS Receiver Cable
2.5.8 Connecting the wiring harness
2.5.9 Connecting the WIFI antenna
2.6.0 Dimmer hub
2.6.1 Final installation checklist
3. Setup Testing ………………………………………………. 42-44
3.1 Platinum setup test procedures
3.2 Platinum help Menu.
4. Platinum System Maintenance………………………………. 44
7. Troubleshooting guide…………………………………….... 45
