Chapter 5: Troubleshooting
analyzer to be tested should remain enabled.
5 From the Logic Analysis System main menu, select Setup→My
16950A→Timing/State (Sampling).....
a Select State Mode.
b Clear the Timing Zoom check box to turn Timing Zoom off.
c Set the Trigger Position to 100% Poststore.
