3 Slide the electrode cartridge into the lid as shown below.
CAUTION
Do not touch the electrodes while the cartridge is in the Agilent 2100 bioanalyzer. The
electrodes and the high voltage power supplies can be damaged.
4 Push the metal front of the cartridge to ensure a tight connection.
5 Push the metal locking lever into the flat (closed) position.
Metal lever
Push here to ensure
tight connection
