Menu Example 1 The following steps show you how to turn on the menu, move up and
down between levels, move across the choices on each level, and turn off
the menu. In this example, you will enable the function generator to
automatically recall the power-down state when power is turned on.
1 Turn on the menu.
You enter the menu on the “
MENUS” level. The MOD MENU is your first
choice on this level.
A: MOD MENU
2
Move across to the
SYS MENU choice on this level.
1
There are six menu group choices available on the “MENUS” level. Each
choice has a letter prefix for easy identification (
A: , B: , etc.).
D: SYS MENU
3 Move down to the “
COMMANDS” level within the SYS MENU.
The
OUT TERM command is your first choice on this level.
1: OUT TERM
4 Move across to the
POWER ON command on this level.
1
There are six command choices available in the SYS MENU. Each choice
on this level has a number prefix for easy identification (
1: , 2: , etc.).
2: POWER ON
Menu On/Off
Shift
> >
¿
>
>
1
You can also use the knob to scroll left or right through the choices on each
level of the menu.
2
Chapter 2 Front-Panel Menu Operation
A front-panel menu tutorial
35
