5 Move down a level to the “PARAMETER” choices.
The first parameter choice is “
DEFAULT” for the POWER ON command
(“
DEFAULT” is the factory setting and is stored in non-volatile memory).
DEFAULT
6 Move across to the
“LAST STATE” choice.
1
There are two parameter choices for POWER ON.
LAST STATE
7 Save the change and turn off the menu.
The function generator beeps and displays a message to show that the
change is now in effect. You are then exited from the menu.
ENTERED
8 Cycle the power to restore the default values.
Turn the function generator OFF and then ON. The default output
state will now be in effect (1 kHz sine wave, 100 mV peak-to-peak,
50
W termination).
¿
>
Enter
1
You can also use the knob to scroll left or right through the choices on each
level of the menu.
Chapter 2 Front-Panel Menu Operation
A front-panel menu tutorial
36
