4 Move down a level to edit the BURST CNT parameter.
The number of cycles should be “1” when you come to this point in the
menu for the first time. For this example, you will set the number of
cycles to “4”. Notice that the
Burst annunciator flashes, indicating that
the displayed value is for the burst mode.
¾00001 CYC
When you see the flashing “
¾” on the left side of the display, you can
press
¾
to abort the edit and return to the “COMMANDS” level.
5 Move the flashing cursor over to edit the last digit.
Notice that the rightmost digit is flashing (the digit wraps around).
00001 CYC
6 Increment the last digit until “4” is displayed.
1
You decrement or increment each digit independently.
00004 CYC
7 Save the change and turn off the menu.
The function generator beeps and displays a message to show that the
change is now in effect. You are then exited from the menu.
ENTERED
<
¾
¿
Enter
¾
¾
1
You can also use the knob or “enter number” mode to enter a number.
See “Front-Panel Number Entry” on page 3 for more information.
2
Chapter 2 Front-Panel Menu Operation
A front-panel menu tutorial
39
