Menu Example 3 Some commands in the menu require that you enter a numeric
parameter value. The following steps show you how to enter a number
in the menu. For this example, you will set the number of cycles for the
burst modulation mode.
1 Turn on the menu.
You enter the menu on the “
MENUS” level. The MOD MENU is your first
choice on this level.
A: MOD MENU
2 Move down to the “
COMMANDS” level within the MOD MENU.
The AM SHAPE command is your first choice on this level.
1: AM SHAPE
3 Move across to the
BURST CNT command on this level.
1
There are ten command choices available in the MOD MENU.
4: BURST CNT
¿
Menu On/Off
Shift
> >
>
1
You can also use the knob to scroll left or right through the choices on each
level of the menu.
Chapter 2 Front-Panel Menu Operation
A front-panel menu tutorial
38
