Service Guide 4
Agilent 35670A Supplement 21
To troubleshoot CPU, memory and buses failures
Step 1: Disregard references to Memory Assembly and
incorporate the related information into A17 CPU.
Step2: Illustration for component locator shows new connector
locations
Page in original guide 4-19
Figure 7 A17 CPU board connector locator, component side
Motherboard connector
Keyboard
connector
Disk drive
connector
Inverter power
connector
P1
P13
P10
P3
