Laboratory Facilities
Agilent 4100 Microwave Plasma Atomic Emission Spectrometer Site Preparation Guide 31
Electrical requirements
Table 4. System electrical specifications
System unit Required supply voltage Nominal rating
4100 MP-AES 200–240 V AC ±10%
Frequency 50–60 Hz ±1 Hz
2.04 kVA
SPS 3 autosampler 96–264 V AC
50–60 ±1 Hz
~220 VA
Personal computer
(Typical)
115, 120, 220, 240 V AC, 50/60 Hz 300 VA
Printer
(Typical)
115, 120, 220, 240 V AC, 50/60 Hz 85 VA
Instrument power connections
Table 5. Instrument power connections
Power supply phase
Single
Cable rating
10 A/250 V AC
Equipment end Supply end
Australia
IEC-60320-C13 AS/NZS-3112 10 A 3 pins
USA
IEC-60320-C13 NEMA 6-15P
Europe
IEC-60320-C13 CEE 7/7
