Accessories and Options
44 Agilent 4100 Microwave Plasma Atomic Emission Spectrometer Site Preparation Guide
Electrical requirements
All power supplies should be single phase AC, three-wire system
(active, neutral, ground or two active and ground) and should be
terminated at an appropriate connection receptacle that is within
reach of the power cable.
The installation of electrical power supplies must comply with the
rules and/or regulations imposed by the local authorities responsible
for the use of electrical energy in the workplace.
The Agilent 4107 Nitrogen Gas Generator is supplied with a 2 meter
long (6 ft 6 in), mains supply cable. The cable is rated to 15 A/250 V
and is terminated as listed in Table 12.
Table 11. Nitrogen generator electrical specifications
System unit Required supply voltage Nominal rating
Nitrogen generator
24 V DC ±5% 50 W
Plug pack
100–240 V AC ±10%
Frequency 47–63 Hz
60 W
(Nominal)
Table 12. System electrical specifications
Power supply phase Single
Equipment end Supply end
Australia
IEC-60320-C13 AS/NZS-3112 10 A 3 pins
USA
IEC-60320-C13 NEMA 5-15P
Europe
IEC-60320-C13 CEE 7/7
Weights and dimensions
See Page 26 for details.
