Agilent 4155C/4156C VXIplug&play Driver User’s Guide, Edition 4 2-15
Driver Function Reference
hp4156b_addStressSyncPulse
Syntax ViStatus _VI_FUNC hp4156b_addStressSyncIv(ViSession vi, ViInt32 source,
ViInt32 channel, ViInt32 mode, ViReal64 range, ViReal64 base, ViReal64 stress,
ViReal64 comp);
Parameters vi Instrument handle returned from hp4156b_init( ).
source Reference number of the stress source. 1, 2, 3, or 4.
channel Channel number of the stress source. 1 to 6 (SMU1 to SMU6),
21 (VSU1), 22 (VSU2), 27 (PGU1), or 28 (PGU2).
mode Source output mode. 1 (current, only for SMU) or 2 (voltage).
range Output ranging mode. 0 (auto) or positive value (limited auto).
base Source output value before stress start trigger (in A or V).
stress Source output value after stress start trigger (in A or V).
comp Compliance value (in V or A). It must be voltage for the current
source, or current for the voltage source.
NOTE range, base, stress, comp parameters
Available values depend on the unit. See “Parameters” on page 2-6.
hp4156b_addStressSyncPulse
This function specifies pulse stress source and sets the parameters. Up to 4 stress
sources can be used at once. Use this function and/or hp4156b_addStressSyncIv to
set the stress sources.
Syntax ViStatus _VI_FUNC hp4156b_addStressSyncPulse(ViSession vi, ViInt32 source,
ViInt32 channel, ViReal64 base, ViReal64 stress, ViReal64 width, ViReal64 delay,
ViReal64 rise, ViReal64 fall);
Parameters vi Instrument handle returned from hp4156b_init( ).
source Reference number of the stress source. 1, 2, 3, or 4.
channel Channel number of the pulse source. 27 (PGU1) or 28 (PGU2)
base Stress pulse base value (in V). See Table 2-8.
stress Stress pulse peak value (in V). See Table 2-8.
width Pulse width (in seconds). See Table 2-9.
