Exercise 1 – Develop an acquisition method
Task 3. Find optimum fragmentor voltage for maximum response
16 Agilent 6400 Series Triple Quad LC/MS Familiarization Guide
2 Set up and run the worklist
(optional).
• Set up six samples with Sample
Name SulfaDrugMix to inject 1ul
from vials 1-6 or the ones you
choose.
• Specify the data files as
iiiSulfaSIMxxx.d, where iii are
your initials and xxx is the
voltage.
a Click the Worklist icon if necessary to
make sure the worklist is visible.
b Click Worklist > New to start a new
worklist. You do not need to save the
last worklist.
c To set up the run, right-click the upper
left corner of the worklist, and click
Worklist Run Parameters.
d Type the paths for the method and
data files.
e Type the information for the 60 voltage
run.
f Click Worklist > Add Sample.
Another sample is added to the
Worklist. Add five samples to the
worklist for voltages 80-220.
g Mark the checkbox to the left of the
Sample Name for each of the six
samples.
• This step is optional because you
can use data files shipped with the
system to perform many of the
tasks in this exercise.
h Start the worklist.
• Click Worklist > Run.
• Click the icon in the main
toolbar.
• Click the icon in the worklist
toolbar.
• Note that the program only runs
those samples that are marked with
a checkmark.
• You can also run the worklist in
locked mode by clicking the lock
button in the main toolbar (the icon
looks like this icon when it is
locked).
Steps Detailed Instructions Comments
