Agilent Technologies 8647A User Manual

1b-20
Operation Reference
Function
• Roaming Mode: SSID, NID
where,
BI: Block Information
AF: Address Field
VF: Vector Field
MF: Message Field
IB: Idle Block
Field Phase A Phase B, C Phase D
Word 0 of
block 0
BI Block Info Dummy Block Info Dummy Block Info
Word 1 of
block 0
BI BIW000
BIW101
a
BIW101
a
Word 2 of
block 0
BI BIW111
BIW101
a
BIW101
a
Word 3 of
block 0
BI
BIW101
a
a. BIW101 System Message: Time Instruction,
Seconds Adjust: 0,
Daylight Savings: No (Standard Time),
Local Time zone: Greenwich Meridian
BIW101
a
BIW101
Word 4 of
block 0
AF Network Address Idle Idle
Word 5 of
block 0
AF Address 1 Dummy Address 1‘ Dummy Address 1
Word 6 of
block 0
AF Address 2 Dummy Address 2 Dummy Address 2
Word 7 of
block 0
VF Short Message Vector
(for Network Address)
VF
b
b. Vector Type: Short Message/Tone Only,
Message Type: 3 Numeric Characters (000) with Short Address
VF
2
Word 0 of
block 1
VF Vector (for Address 1,2) Numeric Vector (for
Dummy Address 1,2)
Numeric Vector (for
Dummy Address 1,2)
Word 1 of
block 1
VF Message Dummy Message Dummy Message
Word 2 of
block 2
MF Message Dummy Message Dummy Message
:: : : :
: IB Idle Idle Idle
:: : : :
