1-116
Making Measurements
Using Test Sequencing to Test a Device
DO SEQUENCE
SEQUENCE 2
SEQUENCE SEQ2
Start of Sequence
Trans:FWD S21 (B/R)
LOG MAG
SCALE/DIV
AUTO SCALE
You can extend this process of calling the next sequence from the last line of the present sequence to 6
internal sequences, or an unlimited number of externally stored sequences.
2. To run both sequences, press:
Loop Counter Example Sequence
This example shows you the basic steps necessary for constructing a looping structure within a test
sequence. A typical application of this loop counter structure is for repeating a specific measurement as you
step through a series of CW frequencies or dc bias levels. For an example application, see
"Fixed IF Mixer
Measurements" on page 2-26.
1. To create a sequence that will set the initial value of the loop counter, and call the sequence that you
want to repeat, press:
This will create a displayed list as shown:
SEQUENCE LOOP 1
Start of Sequence
LOOP COUNTER
10x1
DO SEQUENCE
SEQUENCE 2
To create a second sequence that will perform a desired measurement function, decrement the loop
counter, and call itself until the loop counter value is equal to zero, press:
or on ET models:
