6- 25
Calibrating for Increased Measurement Accuracy
Enhanced Frequency Response Error Correction
the left of the screen, indicating that error correction is on.
Enhanced Reflection Calibration
19. If you are measuring a bilateral device and want to remove the load match error, activate the enhanced
reflection calibration by pressing:
until ON is selected
NOTE You can save or store the measurement correction to use for later measurements. Refer to
Chapter 4 , “Printing, Plotting, and Saving Measurement Results” for procedures.
20. This completes the enhanced response correction procedure. You can connect and measure your device
under test.
