4-38
Printing, Plotting, and Saving Measurement Results
Saving Measurement Results
Figure 4-13 Data Processing Flow Diagram
NOTE If the analyzer has an active two-port measurement calibration, all four S-parameters will be
saved with the measurement results. All four S-parameters may be viewed if the raw data
array has been saved.
1. If you want to title the displayed measurement, refer to "Titling the Displayed Measurement" on page
4-30.
2. Press .
3. Choose one of the following disk drives:
•
• (If necessary, refer to the external disk setup procedure in "Saving an
Instrument State" on page 4-36.)
4. Press .
5. Define the save by selecting from the following choices:
❏
❏
❏
