Making Measurements
Using Markers
Figure 1-29 Example of Searching for the Minimum Amplitude Using a Marker
Searching for a Target Amplitude
1. Press to access the marker search menu.
2. Press to move the active marker to the target point on the measurement trace.
3. If you want to change the target amplitude value (default is 3 dB), press and enter the new
value from the front panel keypad. You may also press to enter
the new value.
4. If you want to search for multiple responses at the target amplitude value, press
and .
Figure 1-30 Example of Searching for a Target Amplitude Using a Marker
