Front Panel Menu Reference "System/Inputs" Menu
Agilent E4419B User’s Guide 3-29
■
Press this softkey to move to the next error in the error queue.
The displayed error message is individually cleared each time
is selected.
■
Press this softkey to return to the “System/Inputs” menu.
•
Press this key to access a menu which allows you to select either
Channel A or Channel B recorder output for setup
modification.Refer to “Recorder Outputs”, on page 2-65 for further
information.
■
Press this softkey to switch the rear panel Recorder Output on
or off. The Recorder Output produces a dc voltage that
corresponds to the selected input channel power level in
Watts.
■
Press this softkey to enter the input power level that you want
to represent the 1 V
dc
maximum output voltage of the
Recorder Output.
■
Press this softkey to enter the input power level that you want
to represent the 0 V
dc
minimum output voltage of the
Recorder Output.
•
Press this softkey to access a menu which allows you to test and
service your power meter.
■
Press this softkey to access the power meter’s self test menu.
◆
Press this softkey to run a series of tests on the power meter.
Refer to “Instrument Self Test”, on page 2-75 for further
information on the tests run.
◆
Press this softkey to verify that the power meter makes an
accurate measurement of it’s 1 mW POWER REF output.
Recorder Output
Output Off On
Max Power
Min Power
Self Test
Instrument Self Test
Confidence Check
