Fundamental Operation
Using Table Editors
Chapter 2 49
Using Table Editors
The PSG signal generator uses table editors to simplify configuration tasks such as creating a
list sweep.
Using the List Mode Values table editor, the following section familiarizes you with basic table
editor functionality.
Press
Preset > Sweep/List > Configure List Sweep.
The signal generator displays the List Mode Values table editor, as shown below.
Active Function Area an area that displays the active table item while its value
is edited
Cursor an inverse video identifier used to highlight specific table
items for selection and editing
Table Editor Softkeys keys that select table items, preset table values and
modify table structures
Table Items values arranged in numbered rows and titled columns
Cursor
Table Editor Softkeys
Table Editor Name
Table Items
Active Function Area
To Next Page
