13
Introduction to the Autosampler
1
Sampling Unit
Sampling Unit
The sampling unit comprises three main assemblies: needle drive, metering
device, and injection valve.
The sampling units for the standard and the preparative autosamplers are
different.
Figure 6 Autosampler Sampling Unit
NOTE
The replacement sampling unit excludes the injection valve and metering head assemblies.
BZiZg^c\YZk^XZ
>c_ZXi^dckVakZ
CZZYaZYg^kZ
