Maintenance
7
Overview of Main Repair Procedures
1Power supply
2 ASM board
3 Transport assembly
4 Metering seal, “Metering Seal and Plunger” on page 98
5Needle, “Needle Assembly” on page 86
6 Rotor seal, “Rotor Seal” on page 94
7Needle seat, “Needle-Seat Assembly” on page 89
