Agilent Technologies N5242A - Front Panel Assembly, Back Side, All Options

6-12 Service Guide N5242-90001
Replaceable Parts PNA Series Microwave Network Analyzers
Replaceable Parts Listings N5242A
Front Panel Assembly, Back Side, All Options
Reference
Designator
Part Number Qty Description
A1
N5240-60046
1
Front panel interface board (until 11-15-07)
N5240-63053 Front panel interface board (after 11-15-07)
A2 N5240-60047 1 USB board
➀
N5242-40001 1 Keypad assembly
➁
0515-0430 12
Machine screw, M3.0 x 6 pan head (9 to attach front panel interface
board to front frame and 3 to attach display cable to display hold down
bracket.)
➂
N5242-40003 1 Touch screen rubber boot
➃
2090-0930 1 Touch screen, 10.4 inch
➄
0515-0372 10
Machine screw, M3.0 x 8 pan head (6 to attach display to front frame
and 4 to attach USB board to front frame.)
➅
E6601-61028 1 Cable, A3 front panel interface board to inverter board
➆
0515-1934 4
Machine screw, M2.5 x 6 pan head (To attach inverter board and USB
controller board to display hold down bracket.)
➇
0950-4420 1 Inverter board
➈
0960-2535 1 USB controller board
➉
0515-1521 2
Machine screw, M3.0 x 5 flat head (To attach power switch assembly
to front frame.)
N5240-60050 1 Power switch board
N5240-40001 1 Power button keypad
8121-1452
1
USB controller board cable harness (until 11-15-07)
W1312-60047 USB controller board cable harness (after 11-15-07)
8121-1451 1 Power switch cable harness
1410-0510 2 Cable clamp (with adhesive backing)
A3
Display assembly
0515-0374
4
Machine screw, M3.0 x 10 pan head (To attach LCD display to hold
down bracket.)
2090-0883
1LCD display
N5242-20121
4 Spacers (For display hold down bracket standoffs.)
N5242-00008
1
LCD display hold down bracket (until 11-15-07)
N5242-00034
LCD display hold down bracket (after 11-15-07)
E6601-61016 1
Display cable
